Solution
IMX222 + DM368


System Structure
Embedded LINUX RTOS ,dual core 32 bits DSP (TI Davinci DM368),
Pure hardware compression, watchdog,128M FLASH,128M DDR2;


Image Sensor
1/3" SONY 2.4 Megapixel High-resolution CMOS Sensor - TI Davinci DM368


Resolution
1920×1080

Minimum Illumination
1Lux-sec

S/N Ratio
>50dB

Focus Mode
Manual Focus

Day/Night
IR cut filter with auto switch, IR sensor.

Network
1 RJ45 Ethernet interface, 10/100M adaptation

Led Controller
1 IR lamp control interface , algorithm control IR lamp open and close

Photoresistance
Support linkage between photoresistance input sign, image, IR-Cut and IR lamp.

Lens
2.8-12mm Manual Zoom Lens

Delay
Within The LAN 0.3S

Frame Rate
2 Megapixel - 25FPS

Video Compression
H.264 /JPEG

Protocol
Protocols: RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/TCP/SMTP


Onvif
Support Onvif 2.0

User Permission
Multi-user Classification Management

Power
DC 12V/1A - Poe 48V

Recording Mode
NVR Local/Recording

Consumption
3.0W

Temperature
-10～55℃

Humidity
0%-90%RH,Without Condensation

Weight
1850g


Main Features

* Superior low-light performance both in VGA mode and HD mode,Support ABLC;


* Support WEB Configuration,IE Surveillance;
* Support Dual Stream;
* Support OSD,Chroma,Brightness,Saturation,Electric Zoom Configuration;
* Support real-time transmission,Center warning and picture pop-up linkage supported ( after motion detection and IO alarm);
* Support DDNS,UPNP remote control;Support Onvif 2.0;Support IR-Cut Switch,Sensible infrared;
